substitutions:
  device_name: kogan_strip_1
  device_ip: 192.168.x.x
  plug_icon: mdi:power-socket-au
  usb_icon: mdi:usb-port
  plug1_restore: ALWAYS_ON
  plug2_restore: ALWAYS_OFF
  plug3_restore: ALWAYS_OFF
  usb_restore: ALWAYS_ON

  # Higher value gives lower watt readout
  current_res: "0.00250"
  # Lower value gives lower voltage readout
  voltage_div: "799"

esphome:
  name: ${device_name}

esp8266:
  board: esp8285

wifi:
  ssid: !secret wifi_ssid
  password: !secret wifi_password
  manual_ip:
    static_ip: ${device_ip}
    gateway: 192.168.x.x
    subnet: 255.255.255.0

logger:

web_server:
  port: 80

api:
  reboot_timeout: 15min
  encryption:
    key: !secret encryption_key

ota:
  password: !secret ota_password

binary_sensor:
  - platform: gpio
    pin:
      number: GPIO0
      mode: INPUT_PULLUP
      inverted: true
    name: "${device_name}_button"
    on_multi_click:
      - timing:
          - ON for 5ms to 350ms
          - OFF for at least 750ms
        then:
          - switch.toggle: relayusb
      - timing:
          - ON for 5ms to 350ms
          - OFF for 5ms to 350ms
          - ON for 5ms to 350ms
          - OFF for at least 750ms
        then:
          - switch.toggle: relay1
      - timing:
          - ON for 5ms to 350ms
          - OFF for 5ms to 350ms
          - ON for 5ms to 350ms
          - OFF for 5ms to 350ms
          - ON for 5ms to 350ms
          - OFF for at least 750ms
        then:
          - switch.toggle: relay2
      - timing:
          - ON for 5ms to 350ms
          - OFF for 5ms to 350ms
          - ON for 5ms to 350ms
          - OFF for 5ms to 350ms
          - ON for 5ms to 350ms
          - OFF for 5ms to 350ms
          - ON for 5ms to 350ms
          - OFF for at least 750ms
        then:
          - switch.toggle: relay3

  - platform: status
    name: "${device_name}_status"

light:
  - platform: status_led
    id: green_led
    pin:
      number: GPIO1
      inverted: true

switch:
  - platform: gpio
    name: "${device_name}_plug1"
    pin: GPIO13
    id: relay1
    icon: ${plug_icon}
    restore_mode: ${plug1_restore}

  - platform: gpio
    name: "${device_name}_plug2"
    pin: GPIO14
    id: relay2
    icon: ${plug_icon}
    restore_mode: ${plug2_restore}

  - platform: gpio
    name: "${device_name}_plug3"
    pin: GPIO3
    id: relay3
    icon: ${plug_icon}
    restore_mode: ${plug3_restore}
    on_turn_on:
      - light.turn_on: green_led
    on_turn_off:
      - light.turn_off: green_led

  - platform: gpio
    name: "${device_name}_usb"
    pin: GPIO15
    id: relayusb
    icon: ${usb_icon}
    restore_mode: ${usb_restore}

sensor:
  - platform: hlw8012
    sel_pin:
      number: GPIO12
      inverted: true
    cf_pin: GPIO04
    cf1_pin: GPIO05
    current:
      name: "${device_name}_current"
      unit_of_measurement: A
    voltage:
      name: "${device_name}_voltage"
      unit_of_measurement: V
    power:
      id: ${device_name}_wattage
      name: "${device_name}_wattage"
      unit_of_measurement: W
    current_resistor: ${current_res}
    voltage_divider: ${voltage_div}
    change_mode_every: 8
    update_interval: 15s

  - platform: total_daily_energy
    name: "${device_name}_daily_energy"
    power_id: ${device_name}_wattage
    filters:
      - multiply: 0.001
    unit_of_measurement: kWh

  - platform: wifi_signal
    name: "${device_name}_rssi"
    update_interval: 5min

  - platform: uptime
    id: uptime_sec
    name: "${device_name}_uptime"
    update_interval: 5min

text_sensor:
  - platform: template
    name: "${device_name}_upformat"
    lambda: |-
      uint32_t dur = id(uptime_sec).state;
      int dys = 0;
      int hrs = 0;
      int mnts = 0;
      if (dur > 86399) {
        dys = trunc(dur / 86400);
        dur = dur - (dys * 86400);
      }
      if (dur > 3599) {
        hrs = trunc(dur / 3600);
        dur = dur - (hrs * 3600);
      }
      if (dur > 59) {
        mnts = trunc(dur / 60);
        dur = dur - (mnts * 60);
      }
      char buffer[17];
      sprintf(buffer, "%ud %02uh %02um %02us", dys, hrs, mnts, dur);
      return {buffer};
    icon: mdi:clock-start
    update_interval: 5min

time:
  - platform: homeassistant
    id: homeassistant_time
